产品展示当前所在位置 :首页 > 产品展示 > 工业相机
HDMI VGA 测量 工业相机
【简述】:
【系列】:工业相机
Function:
Adopt Imported Sony sensor;
Adopt 1/2.33 inch image sensor;
VGA 1080P 60 frame image output;
UI Mouse Operation
VGA port 1080P video recording, U disk Pictures were taken;
Image JPG format, photo size 1080x1920;
Built-in measurement tools, can measure a variety of geometric graphics, measurement data can be imported and exported;
Support manual/automatic exposure/one-key exposure, exposure compensation value adjustment;
Support manual/automatic white balance/one-key white B, R, G, adjustable;
Provide 20 line functions, line color, thickness, position adjustable;
Provide center crosshair display on/off;
Support U disk storage, up to 128GB;
Support remote control operation, take pictures without shaking and the image will be clearer;
Support Chinese, English,languages;
Aluminum alloy casing processed by CNC precision milling technology;

Note: HDMI port output uses HDMI monitor,USB port connect USB mouse, VGA port output uses VGA monitor,  U disk interface, the function is to store pictures and videos!


Feature:
Output Interface:VGA HDMI Output
Sensor:Sony 1/2.33 Inch CMOS Sensor
Measuring Tools:Point-point distance, point-line distance, parallel line distance, horizontal line/vertical line, rectangle, polyline, polygon, circle, arc
Housing:Aluminum Alloy
Pixel Size:2.0um*2.0um
Video Display:VGA HDMI Monitor
Image Resolution:1080x1920
Video Record Resolution:1080p@60FPS
VGA Video Resolution:1920×1080@60F/S
VGA Scale:Support 4:3,16:9,screen
Image and Video Storage:Support
Image and Video Playback:Support
Exposure:Auto Exposure and Manual Exposure(AE value set 1-10)
Eliminate Reflections:Support
U disk Drive:MAX 128G
Video Format:MP4
Image Format:JPG
Camera Interface Mounting Diameter:25mm
Camera Interface Standard:C Mount
Lens Interface:25mm C/CS mount
White balance:One key white balance,Manual balance
Color:Black and White / Color
AWB:WB Color Correction/Auto/Manual
Brightness:0-100%,Adjustable
Contrast:0-100%,Adjustable
Saturation:0-100%,Adjustable
Sharpness:1-10,Adjustable
Sensitivity:1-10,Adjustable
B&W Pictures:Support
Image Freezing:Support
Image Flip:Support
R.G.B Adjustment:Support
U disk Formatting:Support
Same Screen Compare:Support
Avoid Flicker:Auto or 50Hz 60Hz
Horizontal and Vertical Mirroring:Support
Cross Lines:20 Lines.Can set color& width& position
Crosshair:Support
Remote:Infrared Remote Control
Support Languages:Chinese, English
Power:DC 12V/1A


Package includes:
1 x Microscope Camera
1 x 12V/1A Power Supply(EU/ AU Adapter)
