- 225X 450X Monocular lens
- 【Brief】：0.7-4.5X magnification, standard C interface, can be matched with ring light source
- 【Series】：Monocular Lens
Optical magnification: 0.7X-4.5X (zoom ratio 6.5:1)
Effective FNO: 14.4
Depth of field: 2.1mm
Resolution: 12.4um
TV distortion: less than 0.15%
Maximum compatible CCD: 1/2 inch
Installation: C Mount
Fixed position: 50mm
225X Working distance: 95mm-145mm
Magnification: 0.35X - 2.25X (about 30-225X on the display)
MAX visual field: 1.5mm×3mm
MIN visual field: 13mm×23mm
450X Working distance: 95mm-105mm
Magnification: 0.7X - 4.5X (about 70-450X on the display)
MAX visual field: 0.8mm×1.5mm
MIN visual field: 5.5mm×10mm
Effective FNO: 14.4
Depth of field: 2.1mm
Resolution: 12.4um
TV distortion: less than 0.15%
Maximum compatible CCD: 1/2 inch
Installation: C Mount
Fixed position: 50mm
225X Working distance: 95mm-145mm
Magnification: 0.35X - 2.25X (about 30-225X on the display)
MAX visual field: 1.5mm×3mm
MIN visual field: 13mm×23mm
450X Working distance: 95mm-105mm
Magnification: 0.7X - 4.5X (about 70-450X on the display)
MAX visual field: 0.8mm×1.5mm
MIN visual field: 5.5mm×10mm
